  1. Core Concepts

Assets

Overview of assets as they are used on Ango Hub.

PreviousAll Keyboard and Mouse ShortcutsNextAttachments

Last updated 10 months ago

An asset is a piece of data to be annotated. Usually, an asset will be in the form of a file, for example, a .jpg image, a .mp3 audio, or a .txt text.

During labeling, Ango Hub will show annotators one asset at a time. The labeler will then annotate the asset using the labeling tools determined in the label set.

Ango Hub supports different categories of assets. .

.

Asset Attributes

Path

Each asset has a file path associated with it.

To see an asset’s file path, in your project, enter the Assets tab, then hover with your cursor over an asset preview. The asset’s absolute path will be shown.

Thumbnail previews are only shown for videos, and for images under 10MB in size.

Clicking on the “Copy” symbol at the beginning of the path will copy the path to the clipboard.

External ID

Each asset is given a non-unique External ID.

This ID is used throughout the Ango Hub interface to identify the asset.

Hovering the mouse cursor over an externalId will show the full external ID of the asset. Clicking on the “Copy” symbol at the beginning of the ID will copy the ID to the clipboard.

Created At

The Created At attribute shows the date and time when the asset was imported into Ango Hub.

Tasks

Shown in the Tasks column is the task information for each asset.

If a task has been assigned to a user in the stage it is currently in, the letters in the circle are the initials of the user assigned to the task. The small symbol to its top right gives a hint to the task's position in the project's workflow.

When , assets are given an External ID equal to their filenames, including the extension. When uploading assets using the functionality, External IDs are determined by the uploader in the JSON file.

A green checkmark indicates that the task is in the Completed stage.

A blue empty label indicates that the task is in a Labeling stage waiting to be annotated.

A yellow review label indicates that the task is in a Reviewing stage waiting to be reviewed.

A blue filled label at the top of the circle indicates that the labels in the task have been imported externally into Ango Hub.

importing assets from the browser
Cloud Import
See all the supported file types
Check out how to import assets into Ango Hub
More on importing annotations here.
